Testing

This section includes:
•

Sensor test

•
Comm test
•
System download
Sensor test
You should test sensors one at a time to make sure they are sending strong
signals to the panel. You should test the sensors at least once a week.
To perform the sensor test:
1. Enter the Status & Settings menu.
2. Scroll until System Tests is listed, Press Enter.
3. Enter your master code and press OK.
4. Press Sensor Test.
5. All sensors learned into your system will be listed.
6. Test any sensor you want by tripping the sensor (see Table 14 below for
details on how to trip each device).
7. The display will update with the total number of packets received from each
individual sensor (see Table 14 below for minimum number of packets
required).
Table 14: Tripping sensors for sensor test
Sensor Instructions
Hardwire contact Open the hardwire contact
Door/window Open the secured door or window.
Carbon monoxide Press and hold the Test/Hush button (approximately 5
a
alarm seconds) until the unit beeps two times, and then release
the button.
a
Glassbreak Test with an appropriate glass break sensor tester.
Motion sensor Avoid the motion sensor field of view for 5 minutes, and
then enter its view.
Smoke Press and hold the test button until the system sounds
transmission beeps.
30
Minimum
packets
required
1
6 of 8
6 of 8
6 of 8
6 of 8
6 of 8
