System configuration

Your Simon XTi-5 security system allows you to program certain user options.
These options are accessed through the settings menu.

Settings menu

To enter the settings menu, press
screen.
Press to exit a menu or option edit mode and navigate up one level.
The panel automatically returns to the main screen after one minute of inactivity
(4 minutes while performing a sensor test, 5 seconds while entering an access
code).

Code options

The Simon XTi-5 security system provides a system of codes to be entered when
a certain level of authority is required to perform an action. These codes allow
you to activate system options, customize panel operations, and generate a
silent alarm. The default code is based on the code length (3, 4, 5, or 6-digit
code) determined at installation. The code types are listed in Table 12 below.
Table 12: Code types
Code
Master code
User codes 1 through 8 These eight codes are supplemental user codes. You can use these
Duress code
Note: Any combination of invalid codes in excess of 40 key presses (such as
fourteen invalid three-digit codes) will cause a system access alarm. The alarm
locks all touchpads, except key fobs, for 90 seconds.

Menu navigation

Each menu contains a list of options and/or submenus. Changing screens and
navigating menus is accomplished by using the various on-screen interactive
icons. When accessing menus such as Programming or System Tests, the panel
20
located at the bottom right of the main
Description
The master code is the main code used for panel operations. The
default code will be 123, 1234, 12345, or 123456 depending on the
value set by the installer for code length.
codes for panel operations such as disarming, but not programming.
These codes can be any 3, 4, 5, or 6-digits, depending on the code
length.
Use the duress code to generate a silent duress alarm while disarming.
