Installing The Host Os; Installing Rsm; Setting Up Rsm - IBM System Storage DS3500 Introduction And Implementation Manual

Draft Document for Review March 28, 2011 12:24 pm

16.2.1 Installing the host OS

There are various operating systems supported for the RSM host, as shown in "Software
requirements" on page 488. In our example, we used a Red Hat Linux Enterprise License 5
as the host operating system on the RSM server. When installing RHEL5, we selected the
following additional packages:
Expect
libXp-devel
Postfix
net-snmp-utils
KDE desktop environment
See IBM Remote Storage Manager for Storage: Planing, Installation, and User's Guide,
GC26-7933 for specific operating system installation instructions.

16.2.2 Installing RSM

The RSM software can be downloaded from:
http://www.ibm.com/storage/disk/rsm
We installed RSM according to the instructions in IBM Remote Storage Manager for Storage
Planing, Installation, and User's Guide, GC26-7933. After the installation, you have to define
the admin and lservice user IDs.

16.2.3 Setting up RSM

After the installation is complete, we have to set up RSM by performing the following steps:
1. On the Linux login window, perform the following steps:
a. Click Session and select KDE.
b. Log in as the admin user.
c. Click the Manage icon to open a Web browser that shows the main administration
window, as shown in Figure 16-7 on page 504. Click Login.
Chapter 16. IBM Remote Support Manager for Storage
7914RSM.fm
503
