Connecting the M120 Router to a Management Console or Auxiliary Device
Copyright © 2010, Juniper Networks, Inc.
All manuals and user guides at all-guides.com
To use a system console to configure and manage the Routing Engine, connect it to the
appropriate port on the craft interface. To use a laptop, modem, or other
CONSOLE
auxiliary device, connect it to the appropriate
accept a cable with an RJ-45 connector. One RJ-45/DB-9 cable is provided with the
router. To connect a device to the other port, you must supply another cable. For cable
specifications, see "Routing Engine Interface Cable and Wire Specifications for the M120
Router" on page 246.
To connect a management console or auxiliary device:
Turn off the power to the console or auxiliary device.
1.
Plug the female end (shown in Figure 43 on page 83) of the provided serial cable into
2.
the appropriate
CONSOLE
ports on the CIP. The ports labeled
Routing Engine slot (
RE 0
in the lower Routing Engine slot (
Using a 2.5-mm flat-blade screwdriver, tighten the screws on the connector.
3.
Attach the other end of the cable to the console or auxiliary device.
4.

Figure 43: M120 Console and Auxiliary Serial Port Connector

Chapter 9: Connecting the M120 Router to External Devices
port on the craft interface. Both ports
AUX
or port. Figure 44 on page 84 shows the external device
AUX
connect to the Routing Engine in the upper
HOST 0
), and the ports labeled
HOST 1
).
RE 1
connect to the Routing Engine
83
