M120 LED Overview
Craft Interface LEDs
118
All manuals and user guides at all-guides.com
For information about using the CLI to display details about alarms generated by interfaces
and hardware components, see "Troubleshooting Using the Chassis and Interface Alarm
Messages" on page 118.
For information about using the CLI to troubleshoot the Junos OS, see the appropriate
Junos OS configuration guide.
When the Routing Engine detects an alarm condition, it lights the red or yellow alarm
LED on the craft interface as appropriate. To view a more detailed description of the
alarm cause, issue the
show chassis alarms
user@host> show chassis alarms
There are two classes of alarm messages:
Chassis alarms—Indicate a problem with a chassis component such as the cooling
system or power supplies.
Interface alarms—Indicate a problem with a specific network interface.
If you need assistance during troubleshooting, you can contact the Juniper Networks
Technical Assistance Center (JTAC) by using the Web or by telephone. See "Contacting
Customer Support" on page 263.
M120 Router Description on page 3
M120 Router Physical Specifications on page 225
M120 Router Power Requirements on page 237
Craft Interface LEDs on page 118
Component LEDs on page 119
The craft interface is the panel on the front of the router that displays system status and
allows you to troubleshoot the router. The craft interface is located at the top of the
chassis above the FPC card cage.
For more information about using the craft interface, see "M120 Craft Interface Description"
on page 23.
LEDs on the craft interface include the following:
CLI command:
