M120 Multiservice Edge Router Hardware Guide
76
All manuals and user guides at all-guides.com
When the CFPC is about 0.5 in (1 cm) from being fully inserted, release the ejector
8.
level and gently push on the CFPC faceplate until you hear a click as the CFPC contacts
the midplane. The ejector lever engages and closes automatically.
Remove the rubber safety cap from the transceiver on the CFPC faceplate.
9.
Insert the appropriate cable into the transceiver on the CFPC faceplate.
10.
Use one of the following methods to bring the CFPC online:
11.
Press and hold the CFPC online/offline button until the green
the button lights steadily, in about 5 seconds. The LEDs and online/offline button
for each CFPC are located directly above it on the craft interface.
Issue the following CLI command:
user@host>request chassis fpc slot slot-number online
For more information about the command, see the Junos OS System Basics and
Services Command Reference.
CAUTION: After the
removing the CFPC again or removing the CFPC from the other slot.
You can also verify correct CFPC functioning by issuing the
as described in "Maintaining M120 FPCs and CFPCs" on page 106.

Figure 39: Reinstalling a CFPC After Installing the M120 Router

LED lights steadily, wait at least 30 seconds before
OK
Copyright © 2010, Juniper Networks, Inc.
STATUS LED next to
command
show chassis fpc
