M120 PIC Serial Number Label
Copyright © 2010, Juniper Networks, Inc.
All manuals and user guides at all-guides.com
Figure 106: M120 Routing Engine Serial Number Label
M120 Compact FPCs (CFPCs) Overview on page 12
Troubleshooting M120 FPCs and CFPCs on page 121
The serial number label is located on the right side of the PIC (see Figure 107 on page 261),
when the PIC is vertically oriented (as it would be installed in the router). The exact
location may be slightly different on different PICs, depending on the placement of
components on the PIC board.
Figure 107: M120 PIC Serial Number Label
Appendix G: Contacting Customer Support and Returning M120 Hardware
261
