Reinstalling the Power Supplies

Copyright © 2010, Juniper Networks, Inc.
All manuals and user guides at all-guides.com

Figure 36: Reinstalling a FEB After Installing the M120 Router

Reinstall the left power supply first and then the right power supply. To reinstall AC or
DC power supplies (see Figure 37 on page 74):
Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
1.
the strap to an approved site ESD grounding point. See the instructions for your site.
Move the power switch on the power supply faceplate to the standby position, for
2.
the AC power supply. For a DC power supply, switch the circuit breaker on the power
supply faceplate to the off position (
Using both hands, slide the power supply into the chassis until you feel resistance.
3.
Firmly push the power supply into the chassis until it comes to a stop. The power
4.
supply faceplate should be flush with any adjacent power supply faceplates.
Tighten the captive screws on the top and bottom flanges of the power supply
5.
faceplate to secure the power supply in the chassis.
Repeat the procedure for the remaining power supply.
6.
Chapter 7: Installing the M120 Router Without a Mechanical Lift
O ).
