Replacing an M120 DC Power Supply

Copyright © 2010, Juniper Networks, Inc.
All manuals and user guides at all-guides.com

Figure 89: Installing an M120 AC Power Supply

M120 AC Power Supply Description on page 29
Maintaining the M120 Power Supplies on page 115
Electrical Specifications for the M120 AC Power Supply on page 230
In the DC power configuration, the router contains two DC power supplies (see Figure 15
on page 31), located in the right rear of the chassis in slots
A single DC power supply provides sufficient power for a fully configured router.
Each power supply (AC or DC) is hot-insertable and hot-removable.
NOTE: To maintain proper cooling and prevent thermal shutdown of the
operating power supply unit, each power supply slot must contain either a
power supply or a blank panel. If you remove a power supply, you must install
a replacement power supply or a blank panel shortly after the removal.
Removing an M120 DC Power Supply on page 178
Installing an M120 DC Power Supply on page 180
Chapter 14: Replacing M120 Hardware Components
and
PEM0 PEM1
(left to right).
177
