M120 Multiservice Edge Router Hardware Guide
64
All manuals and user guides at all-guides.com
Grasp the handle and pull the fan tray out approximately 1 to 3 inches.
4.
WARNING: To avoid injury, keep tools and your fingers away from the fans
as you slide the fan tray out of the chassis. The fans might still be spinning.
Pause for approximately 15 seconds to allow the fans to stop spinning.
5.
When the fans stop spinning, place one hand under the fan tray to support it and pull
6.
the fan tray completely out of the chassis.

Figure 29: Removing an Upper Front Fan Tray Before Installing the M120

Router
Copyright © 2010, Juniper Networks, Inc.
