Maintaining M120 FPCs and CFPCs

Purpose
Action
Related
Documentation
106
All manuals and user guides at all-guides.com
M120 Router Chassis Description on page 6
M120 Host Subsystem Description on page 18
Taking the M120 Host Subsystem Offline on page 140
Replacing an M120 CB on page 143
Replacing an M120 Routing Engine on page 147
For optimum router performance, verify the condition of the Flexible PIC Concentrators
(FPCs) and compact FPCs (CFPCs). The router can have up to six FPCs, four of Type 1,
2, or 3, and two compact CFPCs, mounted vertically in the FPC card cage at the front of
the chassis, as shown in Figure 1 on page 7.
On a regular basis:
Check the LEDs on the craft interface directly above each FPC slot. The green LED
labeled OK lights steadily when an FPC is functioning normally. For more information,
see "FPC LEDs on the M120 Craft Interface" on page 27.
Issue the CLI
show chassis fpc
shown in the sample output, the value
that the FPC is functioning normally:
user@host> show chassis fpc
Slot State
0 Empty
1 Empty
2 Online
3 Online
4 Online
5 Online
For more detailed output, add the
a slot number ( ), which is optional:
2
user@host> show chassis fpc detail 2
State
Temperature
Total CPU DRAM
Start time
Uptime
For further description of the output from the commands, see the Junos OS System
Basics and Services Command Reference.
M120 Flexible PIC Concentrators (FPCs) Overview on page 9
M120 Compact FPCs (CFPCs) Overview on page 12
command to check the status of installed FPCs. As
Online in the column labeled
Temp CPU Utilization (%)
(C) Total Interrupt
39 1 0
41 0 0
43 0 0
39 0 0
option. The following example also specifies
detail
Online
39 degrees C / 102 degrees F
128 MB
2006-05-02 08:53:29 PDT
1 hour, 51 minutes, 57 seconds
Copyright © 2010, Juniper Networks, Inc.
State indicates
Memory Utilization (%)
DRAM (MB) Heap Buffer
128 1 59
128 1 59
128 1 58
128 3 59
