Insert the appropriate cable into the transceiver on the CFPC faceplate.
11.
Use one of the following methods to bring the CFPC online:
12.
Press and hold the CFPC online/offline button until the green
the button lights steadily, in about 5 seconds. The LEDs and online/offline button
for each FPC are located directly above it on the craft interface.
Issue the following CLI command:
user@host>request chassis fpc slot slot-number online
For more information about the command, see the Junos OS System Basics and
Services Command Reference.
CAUTION: After the
removing the CFPC again or removing the CFPC from the other slot.
You can also verify correct CFPC functioning by issuing the
as described in "Maintaining M120 FPCs and CFPCs" on page 106.

Figure 80: Installing an M120 CFPC

M120 Compact FPCs (CFPCs) Overview on page 12
Maintaining M120 FPCs and CFPCs on page 106
Troubleshooting M120 FPCs and CFPCs on page 121
LED lights steadily, wait at least 30 seconds before
OK
Copyright © 2010, Juniper Networks, Inc.
LED next to
STATUS
command
show chassis fpc
