CAUTION: Do not let fiber-optic cable hang free from the connector. Do
not allow fastened loops of cable to dangle, which stresses the cable at
the fastening point.

Figure 48: Attaching a Cable to an M120 PIC

M120 Power Supplies Description on page 29
Connecting the Grounding Cable to the M120 Router on page 79
Tools and Parts Required to Connect the M120 Router on page 81
General Electrical Safety Warnings for M Series, MX Series, and T Series Routers on
page 208
