Using both hands, slide the power supply into the chassis until you feel resistance.
3.
Firmly push the power supply into the chassis until it comes to a stop. The power
4.
supply faceplate should be flush with any adjacent power supply faceplates.
Tighten the captive screws on the top and bottom flanges of the power supply
5.
faceplate to secure the power supply in the chassis.
Insert the appliance coupler end of each power cord into the appliance inlet on the
6.
power supply faceplate.
Remove the cable restraint from the lower edge of the power supply faceplate by
7.
removing its retainer screw.
Wrap the cable restraint around the power cord, then slide it along the power cord to
8.
a position that enables you to reinstall it in the power supply faceplate.
Reinstall the cable restraint by tightening its retainer screw part of the way into the
9.
power supply faceplate.
Carefully pull the AC power cords through the cable restraint until you have the desired
10.
amount of slack in the power cord.
Tighten the cable restraint retainer screw to hold the power cords in place.
11.
Insert the power cord plugs into an AC power source receptacle. Verify that the power
12.
cord does not block access to router components or drape where people could trip
on it.
NOTE: Each AC power supply has two AC appliance inlets. Each power
supply must be connected to a dedicated AC power feed. For 100-120
VAC, both inlets are used. For 200-240 VAC, only the top inlet is used. For
information about site power preparations, see "M120 Router Power
Requirements" on page 237. For information about connecting the router
to power and ground, see "Connecting Power to an AC-Powered M120
Router" on page 89.
Switch the power switch on the power supply faceplate to the on position (
13.
that the status LED on the power supply faceplate blinks, then lights steadily
approximately one minute after you switch on the power switch.
). Verify
|
