M120 Multiservice Edge Router Hardware Guide
Related
Documentation
54
All manuals and user guides at all-guides.com
On the rear of each rack rail, partially insert a mounting screw into the highest hole
1.
specified in Table 20 on page 52 for the large shelf.
Install the large shelf on the rack. Hang the shelf over the mounting screws using the
2.
keyhole slots located near the top of the large shelf flanges.
Partially insert screws into the open holes in the ears of the large shelf.
3.
Tighten all the screws completely.
4.
M120 Rack Mounting Requirements on page 39
M120 Site Preparation Checklist on page 37
Installation Safety Warnings for M Series, MX Series, and T Series Routers on page 195
