User Guide
b) The following example command uses CURL to make send the update command, and that is followed
by a breakdown of the command's structure:
curl -k -u USERNAME:PASSWORD -X POST -i -H Content-Type:application/json
-d "{\"ImageURI\" : \"http://FILESERVER/RubyPeak-2Fan-2Cpu-si-BMC_FW-Update.bin\",
\"Targets\" : [\"/redfish/v1/UpdateService/SoftwareInventory/BMC\"]}"
https://BMC IP Adress/redfish/v1/UpdateService/Actions/UpdateService.SimpleUpdate
The structure of the POST command can be broken down into three components: the base command with
required headers, the data object containing the address to the firmware update image, and the Redfish
API target that will execute the command.
The base command and headers can be broken down as follows:
• The -k modifier allows a connection to an unsecured server and can be omitted if the user prefers to store
the BMC firmware package on an SSL enabled server.
• The -u modifer enables the Basic Auth requirement and is followed by the USERNAME:PASSWORD of
the account activating the upgrade.
Note: The upgrade must come from an account the appropriate roles and permissions to modify
firmware code.
• -X POST specifies the type of REST command being entered. POST is required for firmware upgrades.
• -i specifies that the HTTP response headers should be included in the response output.
• -H specifies a header to be sent with the response body. In this example the Content-Type header is set
to application/json to let the BMC know to expect a JSON formatted request body.
The data object contains a JSON formatted request body that sets the address of the .bin image on the
host that stores it, and a "Target" that specifies which item in the Software Inventory object to update. In
this case that is set to the BMC.
The final component is the base target that initiates the SimpleUpdate action in the update service.
5. The BMC will commit the update and the response should looking something like the following:
HTTP/1.1 303 See Other
Location: /redfish/v1/TaskMonit/deb1fde1-db8c-44c2-bba6-95d83f2c9e79
Content-Type: application/json
OData-Version: 4.0
Cache-Control: no-cache
Access-Control-Allow-Origin: *
Strict-Transport-Security: max-age=31536000; includeSubdomains; preload
X-UA-Compatible: IE=11
X-Frame-Options: SAMEORIGIN
X-XSS-Protection: 1; mode=block
Content-Length: 154
Date: Fri, 30 Nov 2018 17:16:24 GMT
Server: lighttpd/1.4.48
{"@odata.type":"#Message.v1_0_5.Message","MessageId":"Base.1.1.0.Success","Message":"Successfully
Completed Request","Severity":"OK","Resolution":"None"}
Notice that the response body returns all of the HTTP headers because the -i modifier was set. This is
followed by a JSON formatted response body listing the status of the update and whether it was successful.
