7. Custom Mode

7.1 Allocating Parameter No.

"Custom Mode" allows selection of up to 10 function parameters changed
frequently by customer, thus making data modification easier.
The number "1" to "10" can be allocated as custom parameter No. The
allocated data will be written into built-in non-volatile memory of inverter. Even
if the power is cut off, the data will still be held. (The built-in non-volatile
memory of inverter can be written up to100,000 times. Therefore, do not
allocate the function parameter No. frequently. )

■ Setting Example

Allocate function parameter "P002" (The 1
parameter "U001".
1. Confirm operation status (i.e., stop status or
operation status) (For operation at 50.0 Hz).
2. Press button four times to select Custom Mode.
3. Press button to confirm the current allocated parameter
No.
* When function parameter No. in custom mode is displayed,
a dot will appear behind the letter "P" (i.e., "P.").
(If a password is set beforehand, please enter it. Refer to
parameter P150. )
4. Press and hold
status. (The digital part is flickering.)
5. Press button once to change parameter No. to "P.002".
96
button for 3 s to enter allocation setting
st
Deceleration Time) to custom
