Technical data

3.1

PHOENIX 301; 351 EXPERT forceArc

PHOENIX
Adjusting range Welding current/voltage:
TIG
MMA
MIG/MAG
Duty cycle at 20C
80% DC
100% DC
Duty cycle at 40C
60% DC
100% DC
Load alternation
Open circuit voltage
Mains voltage (tolerances)
Frequency
Mains fuse (safety fuse, slow-blow)
Mains connection lead
Max. connected power
Recommended generator rating
Cosϕ/efficiency
Insulation class/protection
classification
Ambient temperature
Machine/torch cooling
Cooling capacity at 1l/min(¹)
Max. flow rate(¹)
Max. initial coolant pressure(¹)
Max. tank capacity(¹)
Coolant(¹)
Workpiece lead
Dimensions L/W/H [mm]
Weight in kg
Protection classification
Constructed to standards
¹ Machines with water cooling (DW)
Item No.: 099-004833-EWM01
301
5A/10.2V - 300A/22.0V
5A/20.2V - 300A/32.0V
5A/14.3V - 300A/29.0V
300A
270A
300A
250A
10 min. (60% DC ∧ 6 min. welding, 4 min. break)
92V
3 x 400V (-25% to +20%)
3 x 16A
H07RN-F4G4
14.3kVA
19.3kVA
-10C to +40C
Fan / gas or water(¹)
Ex works: KF 23 E (-10C to +40C) or
KF 37 E (-20C to +10C)
50mm²
1100 x 455 x 950
93.5/108(¹)
IEC 60974/EN 60974/VDE 0544
EN 50199/VDE 0544 Part 206/ /
Technical data
PHOENIX 301; 351 EXPERT forceArc
351
5 A/10.2V - 350A/24.0V
5 A/20.2V - 350A/34.0V
5A/14.3V - 350A/31.5V
-
350A
350A
300A
92V
50/60Hz
3 x 25A
17.8kVA
24.0kVA
099/89%
H/IP 23
1200W
5l/min
3.5 bar
12l
70mm
95/111.5 (¹)
IP 23
2
13
