5.2.3.4

Choke effect / dynamics

PHOENIX DRIVE 4 M3.00
Operating
element
PHOENIX DRIVE 4 M3.7x
DYN
- +
m/min
5.2.3.5

Wire burn-back

PHOENIX DRIVE 4 with M3.00 control:
• The settings for superpulses and wire burn-back are made on the M3.10 welding machine control
PHOENIX DRIVE 4 with M3.70 control:
• The settings for superpulses and wire burn-back are made either on the M3.10 welding machine
control or on the M3.71 wire feed unit control
M3.10:
Operating
element
V
A
M
Job Nr
Hold
M3.70:
Operating
element
m/min
Item No.: 099-004833-EWM01
Action Result
"Dynamic correction/choke effect" rotary
switch
Dynamic correction or choke effect setting in 9
stages (hard, narrow to soft, wide arc)
Select Dynamics welding parameter
DYN
Dynamic"
Dynamics setting
Arc harder and narrower
Arc softer and wider
Action Result
Select program sequence mode
1 x
Select "RUECK" parameter using the
x x
and "Down" buttons (left)
Adjust the selected parameter using the
x x
and "Down" buttons (right)
Machine returns to Display mode
3 x
Action Result
Selects wire burn-back
3 sec.
Parameter setting
(setting range 0 to 499)
Functional characteristics
comes on.
MIG/MAG welding
Display
No change
-40 to +40
-40 to +40
Display
Program steps
RUECK 2-500
"Up"
RUECK 2-500
"Up"
Display
39
