5.2.10.3 Powercontrol program torch with one rocker (special function)

Calling up welding JOBs (block JOB mode)
In this operating mode, a total of 27 JOBs (welding tasks) divided into three blocks can be called
up using the torch.
Only program 1 can be used in these JOBs. Simultaneous operation with interfaces such as RINT
X11, BUSINT X10 or DVINT X11 is not possible.
Operating elements
Torch trigger
8
Rocker
7 segment display
The following configurations need to be made in order to use this special function:
• Switch the "Program or Up/Down function" changeover switch to "Program" (see "Internal operating
elements" chapter).
• Switch on Block mode (see "Organising JOBs" chapter)
• Select special JOB 1,2 or 3 (see "Organising JOBs" chapter)
Special JOB 1 (SP1) corresponds to JOB number 129,
Special JOB 2 (SP2) corresponds to JOB number 130,
Special JOB 3 (SP3) corresponds to JOB number 131.
Table: Program torch JOB assignment
JOB no.
Control
selection
JOB "0" on the program torch:
Setpoint values for wire speed, arc correction and dynamics are specified manually on the wire feed unit
control. The Special JOB signal light is on permanently.
All other JOBs on the program torch:
Nine additional JOBs can be called up in each special JOB (see table). Setpoint values for wire speed,
arc correction, dynamics and other parameters must first be stored in the JOB using the welding machine
control or the PC300.Net software. (see also "Organising JOBs" chapter). The Special JOB signal light
flashes.
66
Functions
Welding on/off
Call up 27 JOBs (welding tasks) in three blocks. (see table)
Shows the relevant JOB number assignment (see table).
Welding torch selection
0 1 2
SP1 129 140 141
SP2 130 150 151
SP3 131 160 161
3 4 5
142 143 144
152 153 154
162 163 164
6 7 8
145 146 147
155 156 157
165 166 167
Item No.: 099-004833-EWM01
9
148
158
168
