Mig/Mag Welding; Definition Of Mig/Mag Welding Tasks - EWM PHOENIX 301 EXPERT forceArc Operating Instructions Manual

Functional characteristics

MIG/MAG welding

5.2 MIG/MAG welding
5.2.1

Definition of MIG/MAG welding tasks

The PHOENIX product range has been designed so that it is very easy and quick to operate, but still
provides all the functions one could ever need.
128 JOBs (welding tasks) have been pre-programmed for the most common applications. The JOB is
defined using the four basic welding parameters of welding process, material type, wire diameter and gas
type.
The digital system calculates the required process parameters, such as the welding current, welding
voltage and pulse current according to the operating point specified.
The user need only use the key buttons (signal lamps indicate the welding parameters selected) to enter
the JOB and specify the operating point using one-dial operation on the wire feed button.
According to the pre-programmed JOBs, the typical or frequently used types of gas and wire diameters
for the material are suggested automatically depending on the material type selected. It is impossible to
select inappropriate combinations for welding.
There are presets for other welding parameters such as gas pre-flow, free-burning, etc. for numerous
applications, however these can be changed as necessary.
The parameters and functions described here can also be programmed by PC using the PC300.Net
welding parameter software.
The PHOENIX 301 and PHOENIX 351 series have been optimised for welding with low currents
and are particularly well-suited for wire electrodes from 0.8 to 1.2mm.
