5.10.1.11 Program changeover with standard torch (P8)

Special latched
In the "latched absolute program sequence", the unit starts in the 1st step with absolute program 1.
Releasing the torch trigger (non-latched) switches over to absolute program 2, if the "tstart" start time is
elapsed. Otherwise, the control stays in absolute program 1 and switches to absolute program 2 after
"tstart" is elapsed.
In the 3rd step (torch trigger pressed), the unit switches to absolute program 3. After "t3" is elapsed, the
unit is automatically switched to absolute program 4.
This function is only available if no other accessory components such as remote controls or special
torches are connected.
In this operating mode, the program cannot be switched over during the welding process to the wire feed
machine control.
Special latched special
In the N cycle program sequence, the unit starts in the 1st step with start program P
Releasing the torch trigger (non-latched), switches over to the main program P
already elapsed. Otherwise, the control stays in the start program P
elapsed and then the unit switches over.
Tapping switches to other programs (P
Item No.: 099-004833-EWM01
Action Result
Press key button until only LED
„PROG" is shining
Keep the key button pressed
4 sec.
Release the key button
Set tolerance value for wire speed
Set tolerance value for voltage
tolerance
Wait approx. 5 secs. Tolerance limits
(DV: 10%; U: +/- 5.0 V) were entered.
Figure 5-41
to max. P
A1
Functional characteristics
Advanced functions on the wire feed unit control
until the "tstart" start time is
start
).
A9
Display (example)
Left Right
7,5 (DV) 4 (prog.-no.)
0 (DVGrenz) 2.0 (UKorr)
0 (DVGrenz) 2.0 (UKorr)
10 (DVGrenz) 2.0 (UKorr)
10 (DVGrenz) 5.0 (UKorr)
7.5 (DV) 4 (prog.-no.)
from P
start 1
if the "tstart" start time is
A1
