Technical data

Tetrix 352 AC/DC

8 Technical data
8.1 Tetrix 352 AC/DC
Performance specifications and guarantee only in connection with original spare and
replacement parts!
Welding current setting range
Welding voltage setting range
Duty cycle 25 °C ambient temperature
80%DC
100%DC
Duty cycle 40 °C ambient temperature
60%DC
100%DC
Load alternation
Open circuit voltage
Mains voltage (tolerance)
Frequency
Mains fuse
(safety fuse, slow-blow)
Mains connection lead
Max. connected power
Recommended generator rating
Insulation class
Protection classification
Ambient temperature
Machine cooling
Workpiece lead
Dimensions L/W/H [mm]
Weight
EMC class
Constructed to standards
44
625
375
NOTE
5 A–350 A
10.2 V–24.0 V
∧
10min. (60% DC 6 min. welding, 4 min. break)
3 x 400 V (-25% to +20%)
50/60 Hz
H07RN-F4G4
10.6 kVA
23.9 kVA
-20 °C to +40 °C
654 x 374 x 576
IEC 60974-1, -3, -10
780
Figure 8-1
350 A
320A
350 A
300A
100 V
3 x 25 A
H
IP 23
Fan
2
70 mm
82,0 kg
A
/
099-000139-EW501
01.08.2011
