Wire delivery unit
7-pole connection socket (digital)
• Control lead for wire feed unit
Connecting nipple G¼, shielding gas connection
Spool holder
Rapid-action closure coupling, blue (coolant supply)
Connector plug, welding current "+"
Welding current connection on wire feed unit
Rapid-action closure coupling, red (coolant return)
