5.8

Remote control

Only the remote controls described in these operating instructions may be connected. Plug the
remote control unit into the remote control connection socket on the welding machine or wire
feed unit and lock it only when the machine is switched off.
The remote control is detected automatically when the welding machine is switched on.
5.8.1

R10 manual remote control

Item Symbol Description
6 7 8 9 10
1
5
4 11
3,5
3
2,5
2
1,5
1
0,5 20
m/min
0
1 1
2
2
3
5
7
10
10
- V +
3
Item No.: 099-004833-EWM01
0
"Wire speed" rotary dial
12
13
14 Infinitely adjustable setting of the wire speed from min. to max.
15
16
18
(welding output, one-dial operation)
"Arc length correction" rotary dial
2
3
Arc length correction from -10 V to + 10 V
5
7
19-pole connection socket (analogue)
For connecting the control lead.
Functional characteristics
Figure 5-38
Remote control
83
