Example, Aluminium Welding (Latched Special) - EWM PHOENIX 301 EXPERT forceArc Operating Instructions Manual

Functional characteristics
MIG/MAG welding
5.2.7.7

Example, aluminium welding (latched special)

I
P
Basic parameters
Display
GASstr
GASend:
RUECK
"P " start program
START
DVstart
ustart
tstart
"P " main program
A
"P " reduced main program
B
DV3
U3
"P " end-crater program
END
tSend
DVend
Uend
tend
58
START
P
A
Meaning / explanation
Gas pre-flow time
Gas post-flow time
Wire burn-back length
Wire speed
Arc length correction
Duration
Setting the wire speed
Wire speed
Arc length correction
Slope duration from P
A
Wire speed
Arc length correction
Duration
P
B
Figure 5-24
or P to P
B END
P
END
t
Setting range
0.0s to 20.0s
0.0s to 20s
2 to 500
0% to 200%
-9.9V to +9.9V
0.0s to 20s
0% to 200%
-9.9V to +9.9V
0.0s to 20s
0% to 200%
-9.9V to +9.9V
0.0s to 20s
Item No.: 099-004833-EWM01
