Technical data

Taurus 505

8 Technical data
Performance specifications and guarantee only in connection with original spare and
replacement parts!
8.1 Taurus 505
Setting range for welding current
Setting range for welding voltage
Duty cycle
40%
60%
100%
Load alternation
Open circuit voltage
Open circuit voltage (VRD)
Mains voltage (tolerances)
Frequency
Mains fuse
(safety fuse, slow-blow)
Mains connection lead
Max. connected load
Recommended generator rating
cosϕ
Insulation class/protection classification
Ambient temperature
Machine/torch cooling
Workpiece lead
Dimensions (L x W x H)
Weight
EMC class
Constructed to standards
46
NOTE
MIG/MAG
5 A–500 A
14.3 V–39.0 V
40 °C 25 °C
500 A 500 A
420 A 450 A
360 A 390 A
∧
10 min. (60% DC 6 min. welding, 4 min. pause)
3 x 400 V (-25% to +20%)
50/60 Hz
3 x 35 A
H07RN-F4G4
24.6 kVA
35.0 kVA
H/IP 23
-20 °C to +40 °C
Fan/gas
95 mm
625 mm x 300 mm x 535 mm
IEC 60974 -1, -10
MMA
20.2 V–40.0 V
40 °C 25 °C
500 A 500 A
420 A 450 A
360 A 390 A
79 V
24 V
25.3 kVA
0.99
2
45 kg
A
/
