TIG program sequence ("Program steps" mode)

5.3.7.1

TIG parameter overview

The parameter settings are made on welding machine control M3.10 or M3.11
I
Basic parameters
Display
GASstr
GASend:
"P " start program
START
Istart
tstart
"P " main program
A
tS1
t2
tS3
"P " reduced main program
B
tS2
I3
t3
"P " end program
END
tSe
Iend
tend
P , P , and P
START B
(see chap. 3.14)
Various functional sequences can be set up according to the operating mode.
76
P P
START A
Istart
tstart tS1 t2
Meaning / explanation
Gas pre-flow time
Gas post-flow time
Ignition current
Duration
Slope duration from P
START
Duration
Slope duration from P
B
Slope duration from P
A
Welding current
Duration
Slope duration from P or P
A
Welding current
Duration
are "relative programs", i.e. they relate to percentages of the welding current setting
END
P P
B A
I3
tS2 t3 tS3
Figure 5-36
to P (Upslope)
A
to P
A
to P
B
to P (Downslope)
B END
P
END
Iend
tSe tend
Setting range
0.0s to 0.9s
0.0s to 20s
0% to 200%
0.0s to 20s
0.0s to 20s
0.01s to 20.0s
0.00s to 20.0s
0.00s to 20.0s
0% to 100%
0.01s to 20.0s
0.0s to 20s
0% to 100%
0.0s to 20s
