Functional characteristics
MMA welding
5.4.4

Arcforcing

Operating
element
m/min
5.4.5

Hotstart

The hotstart device improves the ignition of the stick electrodes using an increased ignition current.
a) = Hotstart time
b) = Hotstart current
I = Welding current
t = Time
5.4.5.1

Hotstart current and Hotstart time

Control element Action
V
A
M
Job Nr
Hold
Basic parameters
Display
Ihot
thot
tanti
78
Action Result
Select arcforcing welding parameter
X x
Press until
Arcforcing setting on the "Wire speed/welding
parameters" rotary dial
Result
Select Program sequence mode
1 x
Select the welding parameter using the key
x x
buttons
Adjust the selected welding parameter using the
x x
key buttons
Machine returns to Display mode
3 x
Meaning / explanation
Hotstart current
Hotstart time
Antistick time
DYN
"Dynamic" LED comes on.
"Up" and "Down" (left)
"Up" and "Down" (right)
Display
-40 to +40
-40 to +40
Display
Program Steps
Setting range
0% to 200%
0s to 10.0s
0s to 2.0s
Item No.: 099-004833-EWM01
