EWM PHOENIX 301 EXPERT forceArc Operating Instructions Manual page 69

Panel thickness 20mm, parent metal ST.37-2, filler material SG 2 1.2mm
Seam
Fillet weld 65%Ar, 8%CO
trough
Fillet weld
trough
Fillet weld
trough
Fillet weld 65%Ar, 8%CO
trough
Fillet weld 65%Ar, 8%CO
horizontal
1st layer
Fillet weld
horizontal
2nd layer
To create a rotating arc, the contact tube gap must be at least 30mm.
Item No.: 099-004833-EWM01
Gas/quantity
, 0.5%O , 26.5He,
2 2
e.g. MG T.I.M.E.
22l/min
96%Ar, 4%02,
e.g. MG Argomix 4
22l/min
96%Ar, 4%02,
z.B. MG Argomix 4
22l/min
, 0.5%O , 26.5He,
2 2
e.g. MG T.I.M.E.
22l/min
, 0.5%O , 26.5He,
2 2
e.g. MG T.I.M.E.
22l/min
96%Ar, 4%02,
z.B. MG Argomix 4
22l/min
Functional characteristics
WF Voltage / Curre
m/min correction nt (A)
(V)
27.8 47.4 500
+3.0
25 41.0 430
-5.0
30 43.8 500
-3.0
30 49.0 500
+5.5
22.2 43.6 470
0.0
27.8 46.0 500
-2.4
MIG/MAG welding
Welding speed Stickout
(cm/min) (mm)
(free wire
electrode
end)
40 33
40 33
40 33
40 31
70 36
40 27
69
