Functional characteristics
TIG welding
5.3.5

TIG function sequences / operating modes

The arc ignition takes place with Liftarc (see chapter "TIG Arc ignition"). After unsuccessful
ignition or interruption of the welding procedure, the automatic cut-out takes place (see chapter
"TIG Automatic cut-out").
The welding parameters are optimally preset for a multiplicity of applications (can be adapted if
required (see chapter TIG Program sequence "Program-Steps mode"). In every operation mode
the Superpulse function can be used.
5.3.5.1

Explanation of signs and functions

Symbol Meaning
Press torch trigger
Release torch trigger
Tap torch trigger (press briefly and release)
Shielding gas flowing
I Welding output
Gas pre-flows
Gas post-flows
Non-latched
Special, non-latched
Latched
Special, latched
t Time
PSTAR Ignition program
T
Flat Main program
Hor. Reduced main program
vert.
PEND End program
