3.3

PHOENIX DRIVE 4; 4L; PHOENIX EXPERT DRIVE 4; 4L

PHOENIX
Supply voltage
Max. welding current at 60% DC
Wire feed speed
Standard WF roller fitting
Drive
Torch connection
Protection classification
Ambient temperature
Dimensions (LxWxH) [mm]
Weight
Constructed to standards
3.4

PHOENIX EXPERT DRIVE 4HS

PHOENIX EXPERT DRIVE 4 HS
Supply voltage
Max. welding current at 60% DC
Wire-feed speed
Standard WF roller fitting
Drive
Torch connection
Protection classification
Ambient temperature
Dimensions (L x W x H) [mm]
Weight
Constructed to standards
Item No.: 099-004833-EWM01
PHOENIX DRIVE 4; 4L; PHOENIX EXPERT DRIVE 4; 4L
DRIVE 4
42 VAC / 60 VDC
0.5 m/min to 24 m/min
1.0 + 1.2 mm (for steel wire)
4-roller (37 mm)
Euro-central or Dinse-central
-10°C to +40°C
680 x 460 x 265
approx. 24 kg
IEC 60974 / EN 60974 / VDE 0544
EN 50199 / VDE 0544 Part 206 /
42 VAC / 60 VDC
0.5m/min to 30m/min
1.0 +1.2mm (for steel wire)
4-roller (37mm)
Euro-central or Dinse-central
-10°C to +40°C
680 x 460 x 265
approx. 24.5kg
IEC 60974/EN 60974/VDE 0544
EN 50199/VDE 0544 Part 206/
Technical data
DRIVE 4L
520 A
IP 23
690 x 300 x 410
approx. 18 kg
520 A
IP 23
15
