Functional characteristics
MIG/MAG welding
5.2.3.6

Accessory components for operating point setting

Accessory component
PHOENIX R10 remote control
PHOENIX R20 remote control
PHOENIX R40 remote control
MIG/MAG Powercontrol program torch
MIG/MAG Powercontrol2 torch
PC300.Net PC software
RINT X11 robot interface,
industrial bus interface
5.2.4

MIG/MAG welding data display

To the left and right of the LCD display on the control there are 2 "arrow keys" on each side for selecting
the welding parameter to be displayed. The
bottom upwards and the
As soon as changes have been made to the settings after welding (display on hold values), the display
switches back to the nominal values.
Parameter
Welding current
Material thickness
Wire speed
Welding voltage
Motor current
JOB no.
Operating time
40
button is used to scroll through the parameters from the
button is used to scroll downwards from the top.
Figure 5-7
Before welding
Nominal value
Description
See "Remote controls" chapter
See "Remote controls" chapter
See Phoenix R40 operating instructions
See "MIG/MAG Powercontrol program torch"
chapter
See Powercontrol2 torch operating instructions
See PC300.Net operating instructions
See RINTX11 operating instructions
During welding
Actual value Nominal
value
Item No.: 099-004833-EWM01
After welding
Hold value Nominal
value
