Item Symbol Description
14
15
Super-
puls
SP1
16
SP2
SP3
17
18
Item No.: 099-004833-EWM01
0
LED "Gas post-flow time"
Setting range 0.0 sec to 20.0 sec
"Superpulse" LED
On when the function is activated
"Special job" button
Select the special jobs SP1 to SP3 (JOB 129 to 131)
"Wire inching" button
See also "Commissioning/Inching the Wire Electrode" chapter
"Gas test / rinse" button
• Gas test: For setting the shielding gas quantity
• Rinse: For rinsing longer tube packages
See also "Commissioning/Shielding Gas Supply" chapter
Functional characteristics
Machine control – Operating elements
