Operating instructions
GB
099-000120-EW501
Register now!
For your benefit
Jetzt Registrieren
und Profitieren!
www.ewm-group.com
Welding machine
Tetrix 300 AC/DC Comfort
26.07.2011
*

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tetrix 300 AC/DC Comfort and is the answer not in the manual?

Questions and answers

Related Manuals for EWM Tetrix 300 AC/DC Comfort

Summary of Contents for EWM Tetrix 300 AC/DC Comfort

  • Page 1 Operating instructions Welding machine Tetrix 300 AC/DC Comfort 099-000120-EW501 26.07.2011 Register now! For your benefit Jetzt Registrieren und Profitieren! www.ewm-group.com...

  • Page 2: General Instructions

    © EWM HIGHTEC WELDING GmbH · Dr. Günter-Henle-Str. 8 · D-56271 Mündersbach, Germany The copyright to this document remains the property of the manufacturer.

  • Page 3: Table Of Contents

    Contents Notes on the use of these operating instructions Contents 1 Contents..............................3 2 Safety instructions..........................6 Notes on the use of these operating instructions ................6 Explanation of icons........................7 General ............................8 Transport and installation ......................12 Ambient conditions........................13 2.5.1 In operation........................
  • Page 4 Contents Notes on the use of these operating instructions 5.6.11 Pulses, function sequences ..................43 5.6.11.1 TIG pulses – non-latched operation ..............43 5.6.11.2 TIG pulses - latched operation ..............43 5.6.12 Pulse variants .......................44 5.6.12.1 Pulses (thermal pulses).................44 5.6.12.2 KHz pulses (metallurgic pulses)..............45 5.6.12.3 Automated pulses..................45 5.6.12.4 AC pulses ......................46 5.6.12.5 AC special .....................46...
  • Page 5 9 Accessories ............................84 Remote controls and accessories....................84 Welding torch cooling system ...................... 84 Transportsysteme ........................84 General accessories ........................84 Options............................84 Computer communication......................84 10 Appendix A ............................85 10.1 Overview of EWM branches ......................85 099-000120-EW501 26.07.2011...

  • Page 6: Safety Instructions

    Safety instructions Notes on the use of these operating instructions Safety instructions Notes on the use of these operating instructions DANGER Working or operating procedures which must be closely observed to prevent imminent serious and even fatal injuries. • Safety notes include the "DANGER" keyword in the heading with a general warning symbol. •...

  • Page 7: Explanation Of Icons

    Safety instructions Explanation of icons Explanation of icons Symbol Description Press Do not press Turn Switch Switch off machine Switch on machine ENTER (enter the menu) NAVIGATION (Navigating in the menu) EXIT (Exit the menu) Time display (example: wait 4s/press) Interruption in the menu display (other setting options possible) Tool not required/do not use Tool required/use...

  • Page 8: General

    Safety instructions General General DANGER Electromagnetic fields! The power source may cause electrical or electromagnetic fields to be produced which could affect the correct functioning of electronic equipment such as IT or CNC devices, telecommunication lines, power cables, signal lines and pacemakers. •...
  • Page 9 Safety instructions General WARNING Smoke and gases! Smoke and gases can lead to breathing difficulties and poisoning. In addition, solvent vapour (chlorinated hydrocarbon) may be converted into poisonous phosgene due to the ultraviolet radiation of the arc! • Ensure that there is sufficient fresh air! •...
  • Page 10 Safety instructions General CAUTION Damage due to the use of non-genuine parts! The manufacturer's warranty becomes void if non-genuine parts are used! • Only use system components and options (power sources, welding torches, electrode holders, remote controls, spare parts and replacement parts, etc.) from our range of products! •...
  • Page 11 Safety instructions General CAUTION EMC Machine Classification In accordance with IEC 60974-10, welding machines are grouped in two electromagnetic compatibility classes (see technical data): Class A machines are not intended for use in residential areas where the power supply comes from the low-voltage public mains network.

  • Page 12: Transport And Installation

    Safety instructions Transport and installation Transport and installation WARNING Incorrect handling of shielding gas cylinders! Incorrect handling of shielding gas cylinders can result in serious and even fatal injury. • Observe the instructions from the gas manufacturer and in any relevant regulations concerning the use of compressed air! •...

  • Page 13: Ambient Conditions

    Safety instructions Ambient conditions Ambient conditions CAUTION Installation site! The machine must not be operated in the open air and must only be set up and operated on a suitable, stable and level base! • The operator must ensure that the ground is non-slip and level, and provide sufficient lighting for the place of work.

  • Page 14: Intended Use

    Intended use Applications Intended use This machine has been manufactured according to the latest developments in technology and current regulations and standards. It must only be operated in line with the instructions on correct usage. WARNING Hazards due to improper usage! Hazards may arise for persons, animals and material objects if the equipment is not used correctly.

  • Page 15: Documents Which Also Apply

    Intended use Documents which also apply Documents which also apply 3.2.1 Warranty NOTE For further information, please see the accompanying supplementary sheets "Machine and Company Data, Maintenance and Testing, Warranty"! 3.2.2 Declaration of Conformity The designated machine conforms to EC Directives and standards in terms of its design and construction: •...

  • Page 16: Machine Description - Quick Overview

    Machine description – quick overview Front view Machine description – quick overview NOTE The maximum possible machine configuration is given in the text description. If necessary, the optional connection may need to be retrofitted (see "Accessories" chapter). Front view Figure 4-1 099-000120-EW501 26.07.2011...
  • Page 17 Machine description – quick overview Front view Item Symbol Description Carrying handle Machine control See Machine control – operating elements chapter Connection socket, 19-pole Remote control connection Cooling air inlet Connection socket, welding current “-” (with DC- polarity) connection for Electrode holder Connection socket, welding current “+”...

  • Page 18: Rear View

    Machine description – quick overview Rear view Rear view Figure 4-2 099-000120-EW501 26.07.2011...
  • Page 19 Machine description – quick overview Rear view Item Symbol Description 19-pole mechanised welding interface (analogue) (See chapter entitled "Design and function > interfaces".) analog Connection socket, 7-pole Connection for peripheral devices with digital interface G¼” connecting nipple Shielding gas connection on the pressure regulator Main switch, machine on/off Mains connection cable 4-pole connection socket...

  • Page 20: Machine Control - Operating Elements

    Machine description – quick overview Machine control – Operating elements Machine control – Operating elements Figure 4-3 Item Symbol Description Welding process button MMA welding, lights up in green / arcforce setting, lights up in red TIG welding Operating mode button spotArc (spot time setting range 0.01 sec.
  • Page 21 Machine description – quick overview Machine control – Operating elements Item Symbol Description Alternating current frequency (TIG AC) rotary dial 50 Hz to 200 Hz Alternating current balance (TIG AC) rotary dial Max. setting range: - 30% to + 30% Tungsten electrode diameter/Ignition optimisation rotary dial Infinitely adjustable from 1 mm to 4 mm or greater Welding parameter setting rotary transducer...

  • Page 22: Function Sequence

    Machine description – quick overview Machine control – Operating elements 4.3.1 Function sequence Figure 4-4 Item Symbol Description Select welding parameters button This button is used to select the welding parameters depending on the welding process and operating mode used. Gas pre-flow time (TIG) absolute setting range 0.0 sec to 20.0 sec (0.1s increments).
  • Page 23 Machine description – quick overview Machine control – Operating elements Item Symbol Description AMP% Secondary current (TIG) / pulse pause current Setting range 1 % to 100 % (1 % increments). Percentage of the main current. Down-slope time (TIG) 0.00 s to 20.0 s (0.1 s increments). The down-slope time can be set separately for non-latched and latched.

  • Page 24: Design And Function

    Design and function General Design and function General WARNING Risk of injury from electric shock! Contact with live parts, e.g. welding current sockets, is potentially fatal! • Follow safety instructions on the opening pages of the operating instructions. • Commissioning may only be carried out by persons who have the relevant expertise of working with arc welding machines! •...

  • Page 25: Transport And Installation

    Design and function Transport and installation Transport and installation WARNING Risk of accident due to improper transport of machines that may not be lifted! Do not lift or suspend the machine! The machine can fall down and cause injuries! The handles and brackets are suitable for transport by hand only! •...

  • Page 26: Mains Connection

    Design and function Mains connection Mains connection DANGER Hazard caused by improper mains connection! An improper mains connection can cause injuries or damage property! • Only use machine with a plug socket that has a correctly fitted protective conductor. • If a mains plug must be fitted, this may only be carried out by an electrician in accordance with the relevant national provisions or regulations (any phase sequence for three-phase machines)!

  • Page 27: Tig Welding

    Design and function TIG welding TIG welding 5.6.1 Welding torch and workpiece line connection NOTE Prepare welding torch according to the welding task in hand (see operating instructions for the torch). Figure 5-2 Item Symbol Description Workpiece Connection socket for "+" welding current Workpiece lead connection Welding torch Welding torch hose package...

  • Page 28: Torch Connection Options And Pin Assignments

    Design and function TIG welding If fitted: • Lock connecting nipples of the cooling water tubes into the corresponding quick connect couplings: Return line red to quick connect coupling, red (coolant return) and supply line blue to quick connect coupling, blue (coolant supply). NOTE Please note the relevant documentation of the accessory components.

  • Page 29: Connecting The Shielding Gas Supply

    Design and function TIG welding 5.6.3.1 Connecting the shielding gas supply • Place the shielding gas cylinder into the relevant cylinder bracket. • Secure the shielding gas cylinder using a securing chain. Figure 5-4 Item Symbol Description Pressure regulator Shielding gas cylinder Output side of the pressure regulator Cylinder valve •...

  • Page 30: Setting The Shielding Gas Quantity

    Design and function TIG welding 5.6.3.2 Setting the shielding gas quantity NOTE Rule of thumb for the gas flow rate: Diameter of gas nozzle in mm corresponds to gas flow in l/min. Example: 7mm gas nozzle corresponds to 7l/min gas flow. Incorrect shielding gas setting! If the shielding gas setting is too low or too high, this can introduce air to the weld pool and may cause pores to form.

  • Page 31: Select Welding Task

    Design and function TIG welding 5.6.4 Select welding task NOTE Machine control provides the user with up to 8 welding tasks (JOBs). JOB 0 represents manual operating mode. This is where you can change/optimise all parameters directly in machine control (see chapter "Operating concepts"). It is only possible to change the basic welding parameters if: •...

  • Page 32: Save Welding Tasks (Jobs)

    Design and function TIG welding Item Symbol Description Select welding parameters button This button is used to select the welding parameters depending on the welding process and operating mode used. Welding parameter setting rotary transducer Setting flows, times and parameters. 5.6.4.2 Save welding tasks (JOBs) You can select, change and save the required welding parameters for recurring welding tasks (JOBs) in...

  • Page 33: Arc Ignition

    Design and function TIG welding 5.6.6 Arc ignition 5.6.6.1 HF ignition Figure 5-6 The arc is started without contact from high-voltage ignition pulses. a) Position the welding torch in welding position over the workpiece (distance between the electrode tip and workpiece should be approx. 2-3mm). b) Press the torch trigger (high voltage ignition pulses ignite the arc).

  • Page 34: Optimising The Ignition Characteristics For Pure Tungsten Electrodes

    Design and function TIG welding 5.6.8 Optimising the ignition characteristics for pure tungsten electrodes The best ignition and stabilisation of the arc (DC, AC) and optimum spherical cup formation in the tungsten electrode depend on the electrode diameter being used. The set value should correspond to the diameter of the tungsten electrode.

  • Page 35: Optimal And Fast Spherical Cup Formation

    Design and function TIG welding 5.6.9 Optimal and fast spherical cup formation NOTE A conically ground tungsten electrode (approx. 35°) is generally required to form an ideal spherical cup. Spherical cup formation preset Operating Action Result element spotArc operating mode Switch off pulse welding Set spotArc time in line with the electrode diameter in use (refer to the table of guideline values for spherical cup formation depending on...

  • Page 36: Function Sequences/Operating Modes

    Design and function TIG welding 5.6.10 Function sequences/operating modes The parameters for the function sequence are set using the “Select welding parameters” button and the “Welding parameter setting” rotary dial. Figure 5-8 Item Symbol Description Select welding parameters button This button is used to select the welding parameters depending on the welding process and operating mode used.
  • Page 37 Design and function TIG welding Non-latched mode Figure 5-9 1st cycle: • Press and hold torch trigger 1. • The gas pre-flow time elapses. • HF ignition pulses jump from the electrode to the workpiece, the arc ignites. • The welding current flows and immediately assumes the value set for the ignition current I start •...
  • Page 38 Design and function TIG welding Latched mode AMP% start Down Figure 5-10 Step 1 • Press torch trigger 1, the gas pre-flow time elapses. • HF ignition pulses jump from the electrode to the workpiece, the arc ignites. • Welding current flows and immediately assumes the ignition current value set (search arc at minimum setting).

  • Page 39: Spotarc

    Design and function TIG welding 5.6.10.2 SpotArc The TIG SpotArc function is activated with the pulse variant automated frequencies by default, because this combination produces the most effective results. The user can of course combine the function with other pulse variants depending on the selected welding process. Pulse time (t1) and pulse break time (t2) can be set independently, but the spot time (tP) should be much greater than the pulse time in order to achieve an appropriate result.
  • Page 40 Design and function TIG welding NOTE The process ends when the set spotArc time elapses or if the torch trigger is released prematurely. spotArc/pulse variants table: Process Pulse variants TIG DC Automated pulses (factory setting) Pulses (thermal pulses) (lights up in green) kHz pulse (metallurgic pulses) (lights up in red) No pulses...

  • Page 41: Spotmatic

    Design and function TIG welding 5.6.10.3 Spotmatic The arc is ignited fully automatically without actuating the torch trigger by simply touching the tip of the electrode with the workpiece. Hundreds of reproducible tacks can be made without tungsten inclusions. NOTE Selection and adjustment are made in the same way as with spotArc operating mode (see chapter TIG spotArc).

  • Page 42: Non-Latched Operation, Version C

    Design and function TIG welding 5.6.10.4 Non-latched operation, version C Figure 5-13 1st cycle • Press torch trigger 1, the gas pre-flow time elapses. • HF ignition pulses jump from the electrode to the workpiece, the arc ignites. • Welding current flows and immediately adopts the ignition current value set (search arc at minimum setting).

  • Page 43: Pulses, Function Sequences

    Design and function TIG welding 5.6.11 Pulses, function sequences NOTE The function sequences in pulses basically behave in the same way as in standard welding, but during the main current phase there is a continual switching back and forth between the pulse and pause currents at the relevant times. The pulse function can also be deactivated if necessary during the upslope and downslope phases (see chapter "Advanced settings").

  • Page 44: Pulse Variants

    Design and function TIG welding 5.6.12 Pulse variants NOTE The machines have an integrated pulse device. With pulses, the machine switches back and forth between the pulse current (main current) and pause current (secondary current). 5.6.12.1 Pulses (thermal pulses) With thermal pulses, the pulse and pause times (frequency up to 200 Hz) and the pulse edges (ts1 and ts2) are entered in seconds on the control.

  • Page 45: Khz Pulses (Metallurgic Pulses)

    Design and function TIG welding 5.6.12.2 KHz pulses (metallurgic pulses) The kHz pulses (metallurgic pulses) use the plasma pressure produced at high currents (arc pressure) which is used to achieve a constricted arc with concentrated heat feeding. The frequency can be infinitely adjusted from 50 Hz to 15 kHz and the pulse balance from 1-99 %.

  • Page 46: Ac Pulses

    Design and function TIG welding 5.6.12.4 AC pulses (AC pulse, max. 50Hz) Setting: = pulse current AMP% = pulse pause current / basic current AMP% tpuls = pulse time tpause = pulse pause time pause puls Figure 5-18 5.6.12.5 AC special Application: e.g.

  • Page 47: Tig Activarc Welding

    TIG welding 5.6.13 TIG activArc welding The EWM activArc process, thanks to the highly dynamic controller system, ensures that the power supplied is kept virtually constant in the event of changes in the distance between the welding torch and the weld pool, e.g. during manual welding. Voltage losses as a result of a shortening of the distance between the torch and molten pool are compensated by a current rise (ampere per volt - A/V), and vice versa.

  • Page 48: Welding Torch (Operating Variants)

    Design and function TIG welding 5.6.14 Welding torch (operating variants) Different torch versions can be used with this machine. Functions on the operating elements, such as torch triggers (TT), rockers or potentiometers, can be modified individually via torch modes. Explanation of symbols for operating elements: Symbol Description Press torch trigger...

  • Page 49: Torch Mode And Up/Down Speed Setting

    Design and function TIG welding 5.6.15 Torch mode and up/down speed setting The user has the modes 1 to 6 and modes 11 to 16 available. Modes 11 to 16 include the same function options as 1 to 6, but without tapping function for the secondary current. The function options in the individual modes can be found in the tables for the corresponding torch types.

  • Page 50: Standard Tig Torch (5-Pole)

    Design and function TIG welding 5.6.15.1 Standard TIG torch (5-pole) Standard torch with one torch trigger: Diagram Operating Explanation of symbols elements BRT1 = Torch trigger 1 (welding current on/off; secondary current via tapping function) Functions mode Operating elements BRT 1 Welding current On/Off (factory-set) BRT 1...
  • Page 51 Design and function TIG welding Standard torch with one rocker (MG rocker, two torch triggers) Diagram Operating Explanation of symbols elements BRT 1 = torch trigger 1 BRT 2 = torch trigger 2 Functions mode Operating elements BRT 1 Welding current On/Off Secondary current BRT 2 (factory-set)

  • Page 52: Tig Up/Down Torch (8-Pole)

    Design and function TIG welding 5.6.15.2 TIG up/down torch (8-pole) Up/down torch with one torch trigger Diagram Operating Explanation of symbols elements TT 1 = torch trigger 1 Functions Mode Operating elements BRT 1 Welding current on/off BRT 1 Secondary current (tapping mode) / (Latched mode) (factory- set) Increase welding current, infinite adjustment (up function)
  • Page 53 Design and function TIG welding Up/down torch with two torch triggers Diagram Operating Explanation of symbols elements TT 1 = torch trigger 1 (left) TT 2 = torch trigger 2 (right) Functions Mode Operating elements BRT 1 Welding current on/off BRT 2 Secondary current BRT 1...

  • Page 54: Potentiometer Torch (8-Pole)

    Design and function TIG welding 5.6.15.3 Potentiometer torch (8-pole) NOTE The welding machine needs to be configured for operation with a potentiometer torch (see chap. "Configuring TIG potentiometer torch") Potentiometer torch with one torch trigger: Diagram Operating Explanation of symbols elements BRT 1 = torch trigger 1 Functions...

  • Page 55: Retox Tig Torch (12-Pole)

    Design and function TIG welding 5.6.15.4 RETOX TIG torch (12-pole) NOTE For operation with this welding torch, the welding machine must be equipped with the retrofit option "ON 12POL RETOX TIG" (12-pole torch connection socket)! Diagram Operating elements Explanation of symbols TT= torch trigger BRT 1 BRT 2...

  • Page 56: Setting The First Increment

    Design and function TIG welding 5.6.16 Setting the first increment Figure 5-21 Figure 5-22 Display Setting/selection Exit the menu Exit Torch configuration menu Set welding torch functions Setting the first increment Setting: 1 to 20 (factory setting 1) NOTE This function is only available when using up/down torches in modes 4 and 14! 099-000120-EW501 26.07.2011...

  • Page 57: Mma Welding

    Design and function MMA welding MMA welding CAUTION Risk of being crushed or burnt. When replacing spent or new stick electrodes • Switch off machine at the main switch • Wear appropriate safety gloves • Use insulated tongs to remove spent stick electrodes or to move welded workpieces and •...

  • Page 58: Select Welding Task

    Design and function MMA welding • Insert cable plug of the electrode holder into either the "+" or "-" welding current connection socket and lock by turning to the right. • Insert cable plug of the workpiece lead into either the "+" or "-" welding current connection socket and lock by turning to the right.

  • Page 59: Hotstart Current And Hotstart Time

    Design and function MMA welding Item Symbol Description Alternating current frequency (TIG AC) 50 Hz to 200 Hz (1 Hz increments). Constriction and stabilisation of the arc: The cleaning effect increases with a greater frequency. Particularly thin panels (welding with a low current), anodised sheet aluminium or highly contaminated articles for welding can be welded and cleaned perfectly at a higher frequency.

  • Page 60: Switching The Welding Current Polarity

    Design and function Protecting welding parameters from unauthorised access 5.7.4 Switching the welding current polarity This function can be used to reverse the welding current polarity electronically. For example, when welding with different electrode types for which different polarities are stipulated by the manufacturer, the welding current polarity can be switched easily on the control.

  • Page 61: Remote Control

    Design and function Remote control Remote control NOTE The remote control is operated on the 19-pole remote control connection socket. 5.9.1 Manual remote control RT 1 Functions • Infinitely adjustable welding current (0% to 100%) depending on the preselected main current on the welding machine. 5.9.2 RTG1 19POL manual remote control Functions...

  • Page 62: Manual Remote Control Rt Pws 1

    Design and function Remote control 5.9.7 Manual remote control RT PWS 1 Functions • Infinitely adjustable welding current (0% to 100%) depending on the preselected main current at the welding machine • Pole reversing switch, suitable for machines with PWS function 5.9.8 Foot-operated remote control RTF 1 Functions...

  • Page 63: Pc Interface

    Design and function PC interface 5.10 PC interface CAUTION Equipment damage or faults may occur if the PC is connected incorrectly! Not using the SECINT X10USB interface results in equipment damage or faults in signal transmission. The PC may be destroyed due to high frequency ignition pulses. •...

  • Page 64: Simultaneous Welding On Both Sides, Synchronisation Types

    Design and function Simultaneous welding on both sides, synchronisation types 5.11 Simultaneous welding on both sides, synchronisation types This function is important, if two power sources are used to simultaneously weld on both sides, as is sometimes required for welding thick aluminium materials in the PF position. This ensures that, with alternating currents, the positive and negative pole phases are present on both power sources simultaneously, thus avoiding the arcs negatively influencing each other.

  • Page 65: Interfaces For Automation

    Design and function Interfaces for automation 5.12 Interfaces for automation CAUTION Damage to the machine due to improper connection! Unsuitable control leads or incorrect connection of input and output signals can cause damage to the machine. • Only use shielded control leads! •...

  • Page 66: Remote Control Connection Socket, 19-Pole

    Design and function Interfaces for automation 5.12.2 Remote control connection socket, 19-pole I>0 0-10V 10-100K 10-100K 0-10V +15V (max. 75mA) -15V (max. 25mA) START / STOP AMP / AMP% (PULS) (1V=100A) SOLL Figure 5-26 Pos. Signal shape Designation Output Connection for cable screen (PE) Output Current flows signal I>0, galvanically isolated (max.

  • Page 67: Advanced Settings

    Design and function Advanced settings 5.13 Advanced settings 5.13.1 Setting slope times for secondary current AMP% or pulse edges Figure 5-27 Figure 5-28 Display Setting/selection Expert menu Slope time tS1 (main current to secondary current) Setting: 0.00 s to 20.0 s (factory setting 0.01 s) Slope time tS2 (secondary current to main current) Setting: 0.00 s to 20.0 s (factory setting 0.01 s) 099-000120-EW501...

  • Page 68: Tig Non-Latched Operating Mode, C Version

    Design and function Advanced settings 5.13.2 TIG non-latched operating mode, C version Figure 5-29 Display Setting/selection Exit the menu Exit Machine configuration Settings for machine functions and parameter display Non-latched operation (C version) • on = on • off = off (factory setting) 099-000120-EW501 26.07.2011...

  • Page 69: Configuring The Tig Potentiometer Torch Connection

    Design and function Advanced settings 5.13.3 Configuring the TIG potentiometer torch connection DANGER Risk of injury due to electrical voltage after switching off! Working on an open machine can lead to fatal injuries! Capacitors are loaded with electrical voltage during operation. Voltage remains present for up to two minutes after the mains plug is removed.

  • Page 70: Welding Current Display (Ignition, Secondary, End And Hotstart Currents)

    Design and function Advanced settings 5.13.4 Welding current display (ignition, secondary, end and hotstart currents) The welding currents for secondary current, ignition current and end current (expert menu) can be displayed as percentages (factory setting) or absolute values on the machine display. Figure 5-31 Display Setting/selection...

  • Page 71: Ramp Function Foot-Operated Remote Control Rtf 1

    Design and function Advanced settings 5.13.5 Ramp function foot-operated remote control RTF 1 Figure 5-32 Display Setting/selection Exit the menu Exit Machine configuration Settings for machine functions and parameter display Ramp function Remote control RTF 1 The ramp function can be switched on and off Switch on Switching on machine function Switch off...

  • Page 72: Menus And Sub-Menus On The Machine Control

    Design and function Menus and sub-menus on the machine control 5.14 Menus and sub-menus on the machine control 5.14.1 Direct menus (direct access to parameters) Functions, parameters and their values can be accessed directly, e.g. can be selected by pressing a button once.

  • Page 73: Machine Configuration Menu

    Design and function Menus and sub-menus on the machine control 5.14.3 Machine configuration menu NOTE ENTER (enter the menu) • Switch off machine at the main switch • Press and hold the "welding parameters" button and switch the machine on again at the same time.
  • Page 74 Design and function Menus and sub-menus on the machine control Display Setting/selection Exit the menu Exit Torch configuration menu Set welding torch functions Torch mode • Modes 1-6: with tapping function (factory setting 1) • Modes 11-16: without tapping function Setting the first increment Setting: 1 to 20 (factory setting 1) Up-/Down speed (not available in modes 4 and 14)
  • Page 75 Design and function Menus and sub-menus on the machine control Display Setting/selection Error output to automated welding interface, contact SYN_A AC synchronisation or hot wire (factory setting) Error signal, negative logic Error signal, positive logic AVC (Arc voltage control) connection Automation menu Fast take-over of control voltage (automation) •...

  • Page 76: Maintenance, Care And Disposal

    Maintenance, care and disposal General Maintenance, care and disposal DANGER Risk of injury from electric shock! Cleaning machines that are not disconnected from the mains can lead to serious injuries! • Disconnect the machine completely from the mains. • Remove the mains plug! •...

  • Page 77: Maintenance Work

    Information about giving back used equipment or about collections can be obtained from the respective municipal administration office. • EWM participates in an approved waste disposal and recycling system and is registered in the Used Electrical Equipment Register (EAR) under number WEEE DE 57686922. •...

  • Page 78: Rectifying Faults

    Rectifying faults Customer checklist Rectifying faults All products are subject to rigorous production checks and final checks. If, despite this, something fails to work at any time, please check the product using the following flowchart. If none of the fault rectification procedures described leads to the correct functioning of the product, please inform your authorised dealer.
  • Page 79 Rectifying faults Customer checklist Unstable arc Material inclusions in the tungsten electrode due to contact with filler material or workpiece Regrind or replace the tungsten electrode Incompatible parameter settings Check settings and correct if necessary Pore formation Inadequate or missing gas shielding Check shielding gas setting and replace shielding gas cylinder if necessary Shield welding site with protective screens (draughts affect the welding result) Use gas diffuser for aluminium applications and high-alloy steels...

  • Page 80: Machine Faults (Error Messages)

    Rectifying faults Machine faults (error messages) Machine faults (error messages) NOTE A welding machine error is indicated by the collective fault signal lamp (A1) lighting up and an error code (see table) being displayed in the machine control display. In the event of a machine error, the power unit shuts down.

  • Page 81: Resetting Welding Parameters To The Factory Settings

    Rectifying faults Resetting welding parameters to the factory settings Resetting welding parameters to the factory settings NOTE All customised welding parameters that are stored will be replaced by the factory settings. Figure 7-1 Display Setting/selection Exit the menu Exit Service menu Modifications to the service menu may only be carried out by authorised maintenance staff! Reset (reset to factory settings)

  • Page 82: Display Machine Control Software Version

    Rectifying faults Display machine control software version Display machine control software version NOTE The query of the software versions only serves to inform the authorised service staff! Figure 7-2 Display Setting/selection Exit the menu Exit Service menu Modifications to the service menu may only be carried out by authorised maintenance staff! Software version query (example) System bus ID...

  • Page 83: Technical Data

    Technical data Tetrix 300 AC/DC Comfort Technical data NOTE Performance specifications and guarantee only in connection with original spare and replacement parts! Tetrix 300 AC/DC Comfort Welding current setting range 5 A to 300 A (DC) 5 A to 270 A...

  • Page 84: Accessories

    Accessories Remote controls and accessories Accessories NOTE Performance-dependent accessories like torches, workpiece leads, electrode holders or intermediate hose packages are available from your authorised dealer. Remote controls and accessories Type Designation Item no. RTF1 19POLE 5M Foot-operated remote control current with 094-006680-00000 connection cable Remote control current...

  • Page 85: Overview Of Ewm Branches

    Appendix A Overview of EWM branches Appendix A 10.1 Overview of EWM branches 099-000120-EW501 26.07.2011...
