EWM PHOENIX 301 EXPERT forceArc Operating Instructions Manual page 19

Item Symbol Description
1
2
42V/4A
3
4
digital
5
PC INT
6
7
8
9
10
11
12
analog
13
14
15
Item No.: 099-004833-EWM01
0
Lifting lug
"Automatic cutout" key button
Wire feed motor supply voltage fuse
(press to reset a triggered fuse)
7-pole connection socket (digital)
Wire feed unit connection
7-pole connection socket (digital)
For connecting digital accessory components (documentation interface, robot interface
or remote control, etc.).
PC interface, serial (D-SUB connection socket, 9-pole)
Connection socket, "+" welding current
• MIG/MAG welding:
Connection socket, "-" welding current
• MIG/MAG cored wire welding: Welding current to "WF" central connection/torch
Coolant return from the DV device (red rapid-action closure coupling)
Coolant water supply to the DV device (blue rapid-action closure coupling)
Conveyor rolls, fixed castors
Strain relief with mains connection cable
Automation interface, 19-pole (analogue)
(see Function Specification chapter)
Safety chain
Cooling air outlet
Cylinder bracket
Machine description
PHOENIX 301; 351; 421; 521 EXPERT forceArc
Welding current to "WF" central connection/torch
19
