Functional characteristics
MIG/MAG welding
5.2.2

Selecting MIG/MAG welding tasks

5.2.2.1

Basic welding parameters

The welding task is selected on the welding machine control.
LEDs display the welding parameter selection.
It is only possible to change the 4 basic welding parameters if:
• No welding current is flowing.
• The key switch is set to position "1".
Operating
Element
5.2.2.2

Operating mode

The setting is carried out using the operating elements on the relevant wire feed machine control.
PHOENIX DRIVE 4 / 4L M3.00
Control element Action
PHOENIX DRIVE 4 / 4L M3.7x
5.2.2.3

Welding type

Can only be selected using pulse arc welding machines (PHOENIX PULS).
PHOENIX DRIVE 4 / 4L M3.00
Control element Action
PHOENIX DRIVE 4 / 4L M3.7x
5.2.2.4

Choke effect / dynamics

PHOENIX DRIVE 4 M3.00
Operating
element
36
Action Result
Select welding process
X x
The signal light displays the selection.
Select material type
X x
The signal light displays the selection.
Select wire diameter
X x
The signal light displays the selection.
Select gas type
X x
The signal light displays the selection.
Result
Select operating mode
Select operating mode
X x
The signal light displays the selection.
Result
Select welding type
Select welding type
X x
The signal light displays the selection.
Standard MIG/MAG welding
Pulse arc MIG/MAG welding
Action Result
"Dynamic correction/choke effect" rotary
switch
Dynamic correction or choke effect setting in 9
stages (hard, narrow to soft, wide arc)
Display
No change
No change
No change
No change
Display
No change
No change
Display
No change
No change
Display
No change
Item No.: 099-004833-EWM01
