Covered Operating Elements - EWM PHOENIX 301 EXPERT forceArc Operating Instructions Manual

Functional characteristics
Machine control – Operating elements
5.1.2.1

Covered operating elements

SP1
SP2
SP3
16
Item Symbol Description
1
2
3
4
sec
sec
5
6
DYN
7
8
sec
9
10
sec
sec
11
12
13
sec
30
5
3
EXPERT
sec
sec
6
4
8
15
sec
Super-
puls
2
0
"Select welding parameters" button
This button is used to select the welding parameters depending on the welding process
and operating mode used.
LED "Gas pre-flow time"
Setting range 0.0 sec to 20.0 sec
LED "start program (P
• Wire speed setting range 1 % to 200 % of main program P
• Setting range for arc length correction -9.9 V to +9.9 V
LED "Start time"
Absolute setting range 0.0 sec to 20.0 sec (0.1s increments).
LED "Duration of slope from program P
Setting range 0.0 sec to 20.0 sec (0.1s increments).
LED "Main program (P
• Wire speed setting range WF-min. to WF-max.
• Setting range for arc length correction -9.9 V to +9.9 V
LED "Dynamics"
Setting range -40 to +40
LED "Duration of main program P
Absolute setting range 0.0 sec to 20.0 sec (0.1s increments) for superpulse.
LED "Reduced main program (P
• Wire speed setting range 1 % to 200 % of main program P
• Setting range for arc length correction -9.9 V to +9.9 V
LED "Duration of reduced main program P
Absolute setting range 0.0 sec to 20.0 sec (0.1s increments) for superpulse.
LED "Slope duration from program P
Setting range 0.0 sec to 20.0 sec (0.1s increments).
LED "End program (P
END
• Wire speed setting range 1 % to 200 % of main program P
• Setting range for arc length correction -9.9 V to +9.9 V
LED "Duration of end program P
Setting range 0.0 sec to 20.0 sec (0.1s increments).
7
DYN
M 3.70
10
sec
11
sec
sec
9
13
sec
1
Figure 5-3
)"
START
to main program P
START
)"
A
"
A
)"
B
"
B
or P to end program P
A B
)"
"
END
S
17
12
18
sec
14
A
"
A
A
"
END
A
Item No.: 099-004833-EWM01
