iPF8400SE
4
Grasp the Belt, insert it between the Belt Stopper,
and affix the Belt Stopper with a hex screw at the po-
sition indicated.
•
Here, the Belt Stopper is the one that was removed and stored after initial installation. Neglecting to at-
tach the Belt Stopper may damage the printer.
Important
Do not touch the Linear Scale (a), Carriage Shaft
•
(b), or Fixed Blade (c). This may stain your hands
and damage the printer.
5
Close the Top Cover.
User's Guide
Preparing to Transfer the Printer
573
