Handling rolls

Handling rolls
Loading Rolls on the Roll Holder .............................................................................................................................. 337
Loading Rolls in the Printer ......................................................................................................................................... 339
Changing the Type of Paper ...................................................................................................................................... 343
Specifying the Paper Length ...................................................................................................................................... 345
Removing the Roll from the Printer ......................................................................................................................... 345
Removing the Roll Holder from Rolls ...................................................................................................................... 347
Clearing Jammed Roll Paper ................................................................................................................................ 581
➔
Feeding Roll Paper Manually ....................................................................................................................................... 349
Keeping Track of the Amount of Roll Paper Left ............................................................................................. 349
Specifying the Ink Drying Time for Rolls ............................................................................................................... 350
Specifying the Cutting Method for Rolls ............................................................................................................... 351
Cutting the Leading Edge of Roll Paper Automatically ................................................................................... 357
Reducing Dust from Cutting Rolls ........................................................................................................................... 359
Roll Holder Set .................................................................................................................................................................. 470

Loading Rolls on the Roll Holder

Loading Rolls on the Roll Holder

When printing on rolls, attach the Roll Holder to the roll.
Rolls have a two- or three-inch paper core. Use the correct attachment for the paper core. The printer comes
equipped with the 2-Inch Paper Core Attachment installed.
Using Rolls with a 2-inch Paper Core
Roll Holder Side
No Attachment Needed
• Set the roll on a table or other flat surface so that it does not roll or fall. Rolls are heavy, and dropping a roll may
cause injury.
Caution
• When handling the roll, be careful not to soil the printing surface. This may affect the printing quality. We recom-
mend wearing clean cloth gloves when handling rolls to protect the printing surface.
Important
• Use scissors or a cutting tool to cut the edge of the roll paper if it is uneven, dirty, or has tape residue. Otherwise,
it may cause feeding problems and affect the printing quality. Be careful not to cut through any barcodes printed
on the roll.
• Align the edges of the paper on both ends of the roll. Misalignment may cause feeding problems.
User's Guide
Holder Stopper Side
2-Inch Paper Core Attachment
Using Rolls with a 3-inch Paper Core
Roll Holder Side
3-Inch Paper Core Attachment #1
Loading Rolls on the Roll Holder
Holder Stopper Side
3-Inch Paper Core Attachment #2
337
