DMD2050E Universal Satellite Modem
4.4.1.8

REMOTE AUPC (menu)

NOTE
Remote AUPC Menus are available only when the modem is configured for EF AUPC.
REMOTE AUPC MENU
AUPC MODE {DISABLE,NEAR SIDE,
EFDATA}
LOOPBACK {DISABLE, ENABLE}
TX 2047 TEST {DISABLE, ENABLE}
RX 2047 BER:
4.4.1.9

ITA (menu)

IMPORTANT
When the EBEM Network Specification is selected these parameters are available.
ITA Option {DISABLED, ENABLED}
BPSK 1/2 {NOT SELECTED, SELECTED}
BPSK 2/3 {NOT SELECTED, SELECTED}
BPSK 3/4 {NOT SELECTED, SELECTED}
BPSK 7/8 {NOT SELECTED, SELECTED}
BPSK 19/20 {NOT SELECTED, SELECTED}
QPSK 1/2 {NOT SELECTED, SELECTED}
QPSK 2/3 {NOT SELECTED, SELECTED}
QPSK 3/4 {NOT SELECTED, SELECTED}
QPSK 7/8 {NOT SELECTED, SELECTED}
QPSK 19/20 {NOT SELECTED, SELECTED}
8PSK 1/2 {NOT SELECTED, SELECTED}
MN-DMD2050E Revision 2
Enable or disable the AUPC Function of the remote modem. The
remote AUPC Function is the response of the local modem to
commands for an increase or decrease of the Transmit Power in
0.5 dB steps and the command to change to the setting indicated
in the 'REMOTE CL ACTION' Menu of the remote modem upon
receiver loss of lock.
Enable or disable the Baseband Loopback Test Mode of the
remote modem.
Enable or disable the Transmit 2047 Pattern Test Mode of the
remote modem.
Reports the BER measurement of the receiver 2047 Pattern Test
Mode of the remote modem. BER is reported from the 1x10
1x10 in tenth decade steps. If the pattern does not synchronize
-7
or is out of range, 'NO DATA' is displayed.
User Interfaces
Enable or disable the ITA
Function.
Used to select the mod/code rate
Used to select the mod/code rate
Used to select the mod/code rate
Used to select the mod/code rate
Used to select the mod/code rate
Used to select the mod/code rate
Used to select the mod/code rate
Used to select the mod/code rate
Used to select the mod/code rate
Used to select the mod/code rate
Used to select the mod/code rate
to
-5
4–13
