Advanced Connections - Icom IC-9100 Instruction Manual

2
INSTALLATION AND CONNECTIONS
D
HEADPHONES
D
AH-4 (option)
(p. 29)
Used for connecting a
non-Icom linear amplifier.
25
MIC
The AFSK modulation signal can also
be input to [MIC]. (p. 171)
with
AH-2b (option)
or long wire
(p. 29)
Connect a linear amplifier,
antenna selector, etc.
PREAMP (p. 71)
(144 MHz and 430 MHz)
144 MHz : AG-25 (option)
430 MHz : AG-35 (option)
External all-weather, mast-mounted
preamplifiers are available.
SWR meter, or other device between
the transceiver and preamplifier.
(pp. 28, 29)
EXTERNAL SPEAKER
(MAIN/SUB)
connect a power or
SP-23
(option)
