GPS Set mode

The following individual settings are selectable in the
GPS Set mode. Set them to suit your GPS operating
needs.
q Hold down [CALL/GPS] for 1 second to display the
"GPS" screen.
w Push [SET](F-5) to enter the GPS Set mode.
e Push [Y](F-1) or [Z](F-2) to select the desired
item.
r Rotate [MAIN DIAL] to select the desired option.
ting, if desired.
t Push [MENU] to save, and return to the "GPS"
screen.
1.
Set the baud rate of the GPS receiver to 4800 bps or
9600 bps.
2.
Select either the ddd°mm.mm' or ddd°mm'ss" format
to display position information.
3.
Select either meter or feet/mile format to display the
distance and elevation information.
4.
Select the compass display type.
When the position data is displayed, push [F-1] to se-
lect the compass type.
north.
south.
5.
Set the time difference between UTC (Universal Time
Coordinated) and the local time to between –14:00
and +14:00 in 00:05 steps.
6.
Turn the GPS icon (" ") display function ON or OFF.
" does not appear.
" appears on the display when a valid po-
data is received.
Displays the Set mode
item name and number
-
SET
Ù
Select the item
7.
Select either GPS or Manual to enter your current po-
sition.
°mm.mm'
8.
Manually enter your latitude and longitude data. The
manually programmed data can be memorised.
This item does not appear when "GPS" is selected in

"My Position."

q Push [EDT](F-4) to enter the position data edit
mode.
w Push [Y](F-1) or [Z](F-2) to select "LAT" or "LON,"
and rotate [MAIN DIAL] to enter the desired posi-
tion data.
e Hold down [WR](F-5) to write the data.
GPS/GPS-A OPERATION
[ ] [ ] [ ] [SET]
[MENU] [F-3] [CALL/GPS]
Displays the option
G P S R e c e i v e r B a u d
Ú
1
Reset to the default
setting
However, when the GPS receiver is con-
nected to the transceiver, this setting will
automatically switch to "GPS."
9
[MAIN DIAL]
1
4 8 0 0
2
3
4
5
6
7
8
9
'N
10
'
11
12
13
14
15
16
17
18
19
20
21
