GPS/GPS-A OPERATION
D
Set the following to activate the GPS-A function.
q Push [DV DR] to select the DV mode.
w Enter the GPS Set mode.
e Set the desired position data transmitting interval in
"GPS Auto TX." (p. 134)
r Select "GPS-A" in "GPS TX Mode." (p. 134)
t Set the GPS-A mode operation's items. (pp. 134–
136)
JA3YU
Connect a USB cable* between the transceiver's USB
port on the rear panel and the PC. (p. 26)
When "DV dat" is selected as the "USB2/DATA1 Func"
(63) item option, the GPS-A data can be send from the
USB port. (p. 167)
* Purchase separately
137
our own call sign
Unproto address
Time stamp
AR∗
D
In GPS-A operation, the following codes are transmit-
ted to the PC connected to the IC-9100.
GPS-A code is based on APRS
®
(APRS : Automatic Position Reporting System)
Time stamp H.M.S (Hour/Minute/Second)
D.H.M (Day/Hour/Minute)
Latitude
Longitude
Data extension
GPS-A symbol (Car)
Connect the optional OPC-1529R between the trans-
ceiver's [DATA1] jack on the rear panel and the PC.
(p. 26)
When "DV dat" is selected as the "USB2/DATA1 Func"
(64) item option, the GPS-A data can be send from the
[DATA1] port. (p. 168)
®
code.
Comment
