Receive And Transmit; Operating Ssb - Icom IC-9100 Instruction Manual

4

RECEIVE AND TRANSMIT

q Select the desired frequency band. (p. 35)
w Push [SSB] to select the LSB or USB mode.
when operating below 10 MHz, LSB is selected first.
second to select the data mode, if needed.
e Rotate [MAIN DIAL] to tune a desired signal.
The tuning step can be changed using the tuning step
program mode. (p. 38)
r Rotate [AF] (MAIN Band) to adjust the audio to a
comfortable listening level.
t Push [PTT] on the microphone to transmit. (or
[TRANSMIT] on the transceiver)
y Speak into the microphone at your normal voice
level.
step, if necessary.
u Release [PTT] to receive. (or push [TRANSMIT]
again)
47
[TRANSMIT] TX/RX indicator (MAIN Band)
[AF] [MIC GAIN] [SSB]
(MAIN Band)
"LSB" or "USB" appears
M1
A G C D U P 1 / 4
[MAIN DIAL]
S C P
