14
SET MODE
Set mode description (Continued)
18.
repeater offset for each band.
*The difference between transmit and receive frequencies.
When you select this item, hold down [BAND](MAIN/
SUB) for 1 second to select the desired frequency
band. Then, rotate [MAIN DIAL] to set the offset.
and 9.9999 MHz*.
*99.9999 MHz for the 1200 MHz frequency band.
The default value may differ, depending on the se-
lected frequency band and transceiver version.
tion is OFF for the HF/50 MHz frequency band.
is selected, or the satellite mode is ON.
The optional UX-9100 is required for 1200 MHz frequency
band operation.
19.
Set the one touch repeater shift direction.
receive frequency by the offset amount.
receive frequency by the offset amount.
20.
(Only U.S.A. and Korea versions)
Set the Auto Repeater function ON or OFF.
To activate the Auto Repeater function, first program the
auto repeater frequency range, then select ON. (p. 67)
U.S.A. version:
Korea version:
163
–
–1 ; for U.S.A. version
ON ; for Korea version
21.
Turn the Automatic Antenna Tuner function ON or
OFF. This function is for only the HF bands.
when the SWR is high.
tuning when the SWR is high, even if the tuner
is turned OFF.
22.
Whenever you push [PTT], the internal or external an-
tenna tuner automatically starts tuning if the operat-
-
last-tuned frequency.
you push [PTT] on a new frequency, if the in-
ternal antenna tuner is ON.
(External antenna tuner) Tuning always starts
when you push [PTT] on a new frequency, re-
gardless of whether the external antenna tuner
is ON or OFF.
23.
Select the desired antenna.
The selected antenna's preset memory* is cleared by
holding down [CLR](F-4) for 1 second.
* The variable capacitor settings are memorized as a
preset point for each frequency range (100 kHz steps)
after the tuner matches an antenna.
is cleared.
is cleared.
24.
Set the antenna switch function to Auto, Manual or OFF.
When you change the operating frequency on the HF/
50 MHz frequency band, this function will automatically
select the correct antenna, or you must do it manually.
[ANT1] connector is always selected.
manually change the antenna by pushing
-
