1St If Filter Selection; If (Dsp) Filter Shape - Icom IC-9100 Instruction Manual

D
The IC-9100 has a 15 kHz filter passband width at the
1st IF frequency. The 1st IF filters reduce interference
from strong nearby signals.
If the optional FL-430 1 ST IF FILTER
a 6 kHz filter width can be used. Or, if the FL-431
(3 k is installed, a 3 kHz filter width can be
IF FILTER H
z)
used.
HF/50 MHz band frequency.
q Hold down [FILTER] for 1 second to display the "FIL"
screen (Filter).
w
and have no options.
e Hold down [F-5] for 1 second to select the desired
filter width from 15 kHz
setting, if desired. (The filter passband width setting is
also reset to the default setting.)
r Push [MENU] to save, and exit the "FIL" screen.
D
A soft or sharp type of DSP filter shape for both SSB
and CW can be independently selected.
q Hold down [FILTER] for 1 second to display the "FIL"
screen (Filter).
w Select the SSB or CW mode.
e Push [F-5] once or twice to select either the soft or
sharp filter shape.
r Push [MENU] to save, and exit the "FIL" screen (Fil-
ter).
(6 k H is installed,
z)
1
6 kHz and 3 kHz.
,
ST
[MENU]
B 2 . 4 K
FIL
B W
[MENU]
2 . 4 K
FIL B
B W
B 2 . 4 K
FIL
B W
