Ext-P. Amp (1200); Ext-Sp Separate; Sub Band Mute (Tx); Acc Af/Sql Select - Icom IC-9100 Instruction Manual

47.
Switch the preamplifier control ON or OFF. When
using the optional AG-1200*, ON must be selected.
Otherwise, the preamplifier will not function.
*AG-1200 has been discontinued, but it can be still be used.
NEVER connect any equipment, such
as an SWR or power meter, between the transceiver
and preamplifier due to the transceiver supplies the
DC voltage to the preamplifier unit when the unit is
ON. Otherwise, the preamplifier may not function
correctly, or the transceiver or external equipment
may be damaged.
This item appears only when the optional UX-9100 is
installed.
48.
Select the audio output method when the optional
external speakers are connected to both [EXT-SP
(MAIN)] and [EXT-SP (SUB)] jacks.
separately sent to the [EXT-SP (MAIN)]
and [EXT-SP (SUB)] jacks.
combined and sent to both the [EXT-SP
(MAIN)] and [EXT-SP (SUB)] jacks.
49.
Select the audio output method when headphones are
connected to the transceiver.
separately sent to the right speaker
(MAIN Band) and left speaker (SUB
Band).
combined, and sent to both the right
and left speakers.
MAIN and SUB Band audio are sepa-
rately sent to the right speaker (MAIN
Band) and left speaker (SUB Band).
When the SUB Band is not displayed,
the MAIN Band audio is sent to both the
left and right speakers.
50.
Turn the SUB Band Audio Mute function ON or OFF.
While transmitting, the SUB band audio is muted when
this function is turned ON.
while transmitting.
speaker, is muted while transmit-
ting.
speaker and USB port, is muted
while transmitting.
51.
Set the [ACC] socket's pin 12 (AF) and pin 13 (SQLS)
output usage.
squelch.
squelch.
52.
Set the [DATA2] socket's pin 4 (DATA), pin 5 (AF) and
pin 6 (SQL) output usage.
squelch.
squelch.
53.
Set the [ACC] socket's pin 7 (VSEND) and pin 3
(HSEND) output usage.
HSEND is used for all bands.
1200 MHz bands.
HSEND is used for the HF/50 MHz and
144 MHz bands.
430 MHz, and 1200 MHz bands.
HSEND is used for the HF/50 MHz
bands.
14
SET MODE
166
