EPSON Stylus Photo R1800/R2400

When Measuring Color at a Place the Same as the Repair Work Site

1. Start up the Colorimetric Calibration Tool for Stylus Photo R1800 on a PC,
and click [Perform entire process].
Figure 5-22. Perform Entire Process
Adjustment
The following shows the process when [Perform entire process] is clicked.
Connect printer
Check printer connection
Select port
Ink setup
Perform cleaning
Automatic nozzle check
Executing automatic
nozzle check...
Printing automatic
nozzle check pattern...
End of printing of automatic
nozzle check pattern
Figure 5-23. Entire Process Workflow
Adjustment
Revision B
Print chart
Printing chart...
Dry chart
Measure color
Prepare Calibrator
Prepare chart
Start color measurement
Write Color ID
END
