EPSON Stylus Photo R1800/R2400
Figure 5-52. CCAS Data Viewer Screen
[Next] will not be enabled even if all of the data has been
C A U T I O N
entered in the "Color ID" and "USB ID" edit boxes when
selecting "File" as Input method but not specifying a file.
Adjustment
Clicking the "Browse" button
displays the file selection
dialog box.
The Color ID is displayed in
"Color ID" edit box after the
color measurement data file
is selected.
Adjustment
4. Make sure that the USB ID reflected (entered) at
the USB ID of the currently connected printer, then click [Next] to
write the Color ID to the printer.
Figure 5-53. Write the Color ID
It takes about three minutes to write the Color ID.
C H E C K
P O I N T
Figure 5-54. Writing the Color ID
Revision B
matches
Step 3
162
